Technical Specification
• Engine Type - 561 cc, Single Cylinder, SOHC
• Ignition - ECU
• Starter - Electric
• Bore X Stroke - Ø 95 × 79.2 mm
• Compression Ratio - 10.2
• Fuel System - 42 mm Throttle Body / Programmed Fuel Injection
• Max Power - 44.8 HP / 6500 rpm
• Max Torque - 46.5 Nm / 5500 rpm
• Drive System - 4 × 4 Shaft Drive
• Gear Selection - L/H/N/R/P
• Transmission - V-Belt CVT Automatic
• Engine Braking System - Standard
• Override Button - Standard
• Front Suspension - Dual A-arm
• Rear Suspension - Dual A-arm with Anti-roll Bar
• Front / Rear Brake - Hydraulic Disc with piston caliper and Hydraulic Foot Brake
• Parking Brake - Park In Transmission / Lockable Hand Lever
• Front Tire - AT 25 × 8 – 12 , 6 PLY
• Rear Tire - AT 25 × 10 – 12 , 6 PLY
• Wheelbase (mm) - 1290
• Overall Length (mm) - 1950
• Overall Width (mm) - 1240
• Overall Height (mm) - 1280
• Fuel Capacity - 18L
• Electrical Outlet Connector - 2 DC 12V 10A 120W
• Instrumentation- Digital instrument panel with odometer, speedmeter, Tripmeter, RPM, transmission position, fuel gauge, Hi-Temp/Low-Battery lights, high beam light, EFI checking, differential indicator, 2WD/4WD indicator, EPS indicator
• Color - Matt Black
